| Brand Name : | KXD |
| Model Number : | KXD-CATTLE |
| Certification : | ISO9001&CE Certification |
| Price : | 200-300 USD/set |
| Payment Terms : | MoneyGram,Western Union,T/T,D/P,D/A,L/C |
| Supply Ability : | 15000 sets Per Month |
| Delivery Time : | 15-35 days |
Factory Directly Newborn Hutch Calf Livestock Care Room Newborn Calf Protection Island In Stock
Types of Cattle Shed
Open side wall shed | This kind shed usually build in countries where the temperature range is from 15 °C to 25 °C. this shed with single-layer steel sheet as roof panel. steel fence around the shed instead of the wall panel. this kind shed is economical |
Semi-open wall shed | This kind shed usually build in countries where the temperature range is from 25 °C to 36 °C. this shed with steel sheet+glass wool roller as roof panel or EPS/rock wool/PU sandwich panel as roof.. steel fence around the side wall of shed instead of the wall panel. steel sheet as end wall panel.When the temperature is high in summer, fixed curtains on the side walls to provide shade and cool down. |
Closed shed | This kind shed usually build in countries where the temperature range is below 15 °C in winter or over 36 °C in summer. this shed with EPS/rock wool/PU sandwich panel as roof. panel and wall panel.. the ventilator will be on roof for ventilation. |
Brief Introduction
The "Young Calves" is composed of a box type cowshed and a fence, with one side open and three sides closed. It is placed outside the shed in a sunny and dry place, warm in winter and cool in summer. Single pen feeding of calves facilitates workers to clean and disinfect the calves and their living environment, avoiding mutual sucking between calves, and reducing the incidence of dementia and gastroenteritis. It can increase the survival rate of calves to over 90%. This method can ensure rapid growth of the herd.
Specification
Model | Size Available | Size Available | Size Available |
Dimension | 1500x1200x1200mm | 2200x1200x1400mm | 2500x1600x1400mm |
Material | Poly Ethylene | Poly Ethylene | Poly Ethylene |
Thickness | 3-4mm | 3-4mm | 3-4mm |
Weight | 36kgs | 42kgs | 60kgs |
QTY/20FT Containe | 75pcs | 65pcs | 35pcs |
QTY/40FT Container | 170pcs | 117pcs | 52pcs |
Details Images
◎Made from food grade heavy-duty, impact resistant polyethylene.One shot Rotomolded process brings the calf hutch more strength and long-life usage, no rust forever and ECO friendly,-40°C strength testing passed.
◎Easy installation and moving, labor saving.
◎Round swing rear window let more air flow inside.
◎Rounded edge design protects animal from bruise.
◎High standard galvanized steel rod or pipe and plastic fence can be customized. ◎Front fence is with two bucket holders,suitable for plastic or stainless buckets. ◎Fence, buckets,feeders and hay rack are all for extra component purchasing.
Advantages
Stainless steel food-grade barrels, safe and reliable feeding, feed can be disassembled, easy to clean
One-piece moulding, smooth appearance, no burrs, provide a healthy and comfortable environment for calves, conducive to growth.
One big and three small, can be opened or closed, can independently adjust the air flow, the top large vent add bedding more convenient air circulation, better ensure the growth of calves.
Side stiffener new design, more stiffener helps the hutch stability, weather resistance, tear resistance, resistance to falls,longer service life.
8MM thickened hot-dip galvanized fence, three-piece assembly, easy to use, free to disassemble and assemble.
Customized Service
Our cattle(cow) shed is not only produced based on your
drawings,but also can customized according to your details
requests.
whether a small family farm or a large-scale livestock farm, we
will do you the best proposal. For example, if your site is small, we will provide a compact but practical shed plan, if your site is
large plus expect large-scale breeding, we will provide a spacious, comfortable and fully function shed plan.
Animal Identification & Intelligent Weighing System
Other Accessories
On-site Installation
Quality & Control
Our Service
1. Reply your enquiry in 24 working hours;
2. Experienced and professional staffs will answer all your
questions in fluent English;
3. Customized design is available.
4. Exclusive & unique solution can be provided by our well-trained
and professional engineers;
5. Special discount can be offered with large quantity;
6. We will try our best to meet your requirements and supply you
best quality of the products .
Package & Loading
Product Packaging:
All components are packed in bundles and secured with steel straps.
The main frame is packed in a container or shipped as a single package.
Wall and roof panels are packed separately to avoid damage during shipping.
All necessary fittings and accessories are included in the package.
Our Factory
Why Choose Us
All of our KXD steel structure are ISO 9001-2015 certified. Any third-party inspection will be accepted, such as SGS, BV, TUV etc. We also welcome OEM and ODM orders. So far, we have exported to more than 1,500 projects over 130 countries and regions around the world and accumulated rich experience in the design, fabrication and supply of steel buildings, as well as the erection of steel buildings, architectural materials, electrical systems .You can talk to our customer service center about your sourcing requirements.
|
|
